AE-MB-GS-OX05B1S-C-87 | 5MP Global Shutter MIPI Board Camera Module

Categories 3-7.9 Mega Pixel, Board Camera, Camera Type, Global, Resolution, Shutter type

Main features:

Image Sensor: 1/2.53” OX05B1S-E89Y RGB
Shutter type: Global shutter
Resolution: 5 Megapixel
Interface: MIPI
FOV: D100° H87° V71°
Focus type: Fixed Focus
Dimensions: 13.6X13.6X16.23mm

Customization options:

Lens (FOV, F#, Distortion etc.)
Board size customization
Connector / Pin Assignment

Target application:

Autonomous driving
3D mapping
Driver monitor system
Occupant monitor system
Security
Videoconferencing

Download the Product Brief

Overview:

The AE-MB-GS-OX05B1S-C-87 is a 5MP RGB MIPI board camera based on the OmniVision OX05B1S automotive global shutter image sensor that can generate a full resolution of 2592 (H) × 1944 (V) pixels.

The AE-MB-GS-OX05B1S-C-87 provides outstanding image quality. With its clever design and sophisticated camera functions on-chip, it is the ideal solution for the design of tomorrow’s smart and optimized systems. The AE-MB-GS-OX05B1S-C-87 board camera can generate a HD resolution (720p) image at up to 60 frames per second (FPS).

Using a 87-degree horizontal field of view lens, AE-MB-GS-OX05B1S-C-87 provides outstanding image quality and suitable for a variety of applications.
